DURABLE 92 Casement Window Package — 6 m², 2 Opening Sashes
- Confirm required certification
Design & construction
This is the 6 m² package listing for the 92 thermal-break casement system, with two opening sashes. The detail graphic specifies 1.4 mm profile walls and 5+27A+5 double tempered glazing, together with the screen and hardware listed for the package.
Configuration notes & source
Construction and configuration
- Package Area: 6 m²
- Included Opening Sashes: 2 opening sashes
- Main Profile Wall Thickness: 1.4 mm
- Standard Glazing: 5 mm tempered glass + 27 mm cavity + 5 mm tempered glass
- Gasket: Automotive-grade gaskets, as described by the source
- Hardware: Guyu / Haobo hardware options, as named in the source graphic
- Surface Finish: Fluorocarbon coating
- Interior Colors: Metallic gray / woodgrain finish
- Exterior Colors: Sand gray / coffee
Construction information and domestic performance grades are taken from this product’s official JD page. Confirm the final configuration and applicable test reports with the project quotation.
Source reference: Delburg manufacturer listing · SKU 10098185658620. Product identifier, store and specifications checked on 29 October 2026. English text and images are localized summaries of this listing.
Full Specifications
| Frame Material | Thermal-break aluminum |
|---|---|
| Catalog Entry | 6 m² window package |
| Series | 92 package |
| Opening | inward opening / outward opening |
| Air Tightness (JD listing) | Grade 7 |
| Water Tightness (JD listing) | Grade 5 |
| Wind Resistance (JD listing) | Grade 7 |
| Sound Insulation (JD listing) | Grade 3 |
| Thermal Insulation (JD listing) | Grade 7 (2.0>K≥1.6) |
| Performance Data Source | Official JD listing and product-information graphics; domestic grades are not EN/ASTM test classifications |
| Package Area | 6 m² |
| Included Opening Sashes | 2 opening sashes |
| Glass Type | Tempered glass |
| Screen | Included |
| Main Profile Wall Thickness (JD listing) | 1.4mm |
| Functions (JD listing) | sound insulation / heat retention / thermal insulation / dust / haze protection |
| Screen Style | Security-mesh screen |
| System Window | Yes |
| Hardware Inclusion | Included |
| Main Profile Wall Thickness (detail graphic) | 1.4 mm |
| Standard Glazing (detail graphic) | 5 mm tempered glass + 27 mm cavity + 5 mm tempered glass |
| Gasket (detail graphic) | Automotive-grade gaskets, as described by the source |
| Hardware (detail graphic) | Guyu / Haobo hardware options, as named in the source graphic |
| Surface Finish (detail graphic) | Fluorocarbon coating |
| Interior Colors (detail graphic) | Metallic gray / woodgrain finish |
| Exterior Colors (detail graphic) | Sand gray / coffee |
Model-Specific Construction & Performance
Thermal Performance
JD thermal-insulation classification: Grade 7 (2.0>K≥1.6). These are domestic listing grades; a configuration-specific test report is required for project specification.
Acoustic Performance
JD sound-insulation classification: Grade 3. The listing does not supply a verified Rw/STC value for the final project configuration.
Air, Water & Wind
JD listing: air tightness Grade 7; water tightness Grade 5; wind resistance Grade 7. Domestic classifications, not EN/ASTM equivalences.
Profile & Glazing
Thermal-break aluminum. Main profile wall: 1.4 mm. Glazing: 5 mm tempered glass + 27 mm cavity + 5 mm tempered glass.
Hardware & Screens
Hardware: Guyu / Haobo hardware options, as named in the source graphic. Screen: Included.
Finish & Configuration
Fluorocarbon coating Package: 6 m² with 2 opening sashes. Opening: inward opening / outward opening. Confirm finish, dimensions and selected options with the quotation.
Size & Budget Reference
Use this for early planning only. Your final configuration, engineering review and project-specific quote are confirmed with our team.
