DURABLE Custom Resin Composite Tilt & Turn Window
- Confirm required certification
Design & construction
This is a made-to-measure window enquiry listing rather than one fixed technical configuration. Its title identifies a resin-composite casement / tilt-and-turn window, while the detail graphic presents Jingjia, Meijia, Anju 80 and Youju 100 options.
Configuration notes & source
Construction and configuration
- Series Options: Jingjia / Meijia / Anju 80 / Youju 100; select the system before confirming specifications
- Jingjia Profile: Honeycomb multi-chamber design; 2.6 mm wall stated for this option
- Meijia Profile: Six-chamber multi-seal design; 3.0 mm wall stated for this option
- Anju 80 Option: Thermal-break aluminum; 1.6 mm wall; double tempered glazing
- Youju 100 Option: Thermal-break aluminum; 1.6 mm wall; double tempered glazing
- Gasket Options: EPDM gaskets shown
- Hardware Options: Custom hardware; depends on selected system
Configuration to confirm
The graphic covers several different material systems. Wall thickness, glazing, hardware and colors must be confirmed for the selected series; the alternative-series values are not specifications for one fixed product.
Construction information and domestic performance grades are taken from this product’s official JD page. Confirm the final configuration and applicable test reports with the project quotation.
Source reference: Delburg manufacturer listing · SKU 10086278748687. Product identifier, store and specifications checked on 29 October 2026. English text and images are localized summaries of this listing.
Full Specifications
| Frame Material | Resin composite |
|---|---|
| Catalog Entry | Custom-made window configuration |
| Series | Custom configuration |
| Opening | inward opening / tilt inward |
| Air Tightness (JD listing) | Grade 6 |
| Water Tightness (JD listing) | Grade 5 |
| Wind Resistance (JD listing) | Grade 7 |
| Sound Insulation (JD listing) | Grade 4 |
| Thermal Insulation (JD listing) | Grade 8 (1.6>K≥1.3) |
| Performance Data Source | Official JD listing and product-information graphics; domestic grades are not EN/ASTM test classifications |
| System Window | Yes |
| Functions (JD listing) | sound insulation / heat retention / water resistance / wind resistance / thermal insulation / dust / haze protection |
| Series Options (detail graphic) | Jingjia / Meijia / Anju 80 / Youju 100; select the system before confirming specifications |
| Jingjia Profile (detail graphic) | Honeycomb multi-chamber design; 2.6 mm wall stated for this option |
| Meijia Profile (detail graphic) | Six-chamber multi-seal design; 3.0 mm wall stated for this option |
| Anju 80 Option (detail graphic) | Thermal-break aluminum; 1.6 mm wall; double tempered glazing |
| Youju 100 Option (detail graphic) | Thermal-break aluminum; 1.6 mm wall; double tempered glazing |
| Gasket Options (detail graphic) | EPDM gaskets shown |
| Hardware Options (detail graphic) | Custom hardware; depends on selected system |
| Configuration Confirmation | The graphic covers several different material systems. Wall thickness, glazing, hardware and colors must be confirmed for the selected series; the alternative-series values are not specifications for one fixed product. |
Model-Specific Construction & Performance
Thermal Performance
JD thermal-insulation classification: Grade 8 (1.6>K≥1.3). These are domestic listing grades; a configuration-specific test report is required for project specification.
Acoustic Performance
JD sound-insulation classification: Grade 4. The listing does not supply a verified Rw/STC value for the final project configuration.
Air, Water & Wind
JD listing: air tightness Grade 6; water tightness Grade 5; wind resistance Grade 7. Domestic classifications, not EN/ASTM equivalences.
Profile & Glazing
Alternative systems in this listing: Jingjia, Meijia, Anju 80 and Youju 100. Resin-composite and aluminum options have different specifications; confirm the selected system.
Hardware & Screens
Hardware: Custom hardware; depends on selected system. Screen: Screen configuration to confirm..
Finish & Configuration
Finish depends on the selected system. Opening: inward opening / tilt inward. Confirm finish, dimensions and selected options with the quotation.
Size & Budget Reference
Use this for early planning only. Your final configuration, engineering review and project-specific quote are confirmed with our team.
Documents for Your Project Team
Share the right information with architects, installers and procurement teams before requesting a detailed quote.
Product Datasheet
Installation Guide
CAD Drawings
Get a Project-Specific Recommendation
Share dimensions, drawings or a reference photo. We will help match the system, glazing and hardware before preparing your itemized quote.
What we review
- System, glazing and hardware recommendations
- Sash dimensions and project-specific configuration
- Budget reference and the next drawing requirements
or write to [email protected] · replies within 24 hours
